Summary
A wastewater treatment facility required an accurate representation of its aeration building ahead of a system upgrade. Prashant led the multidisciplinary scan-to-BIM effort, establishing a validated architectural, structural and MEP baseline from point cloud data.
Core challenge
Upgrade design decisions hinged on reliable existing-conditions data
Architectural, structural and MEP information had to be reconciled against the scan and across disciplines
Latent conflicts between existing elements posed a risk to downstream design if left unidentified
Our solution
- 01
Multidisciplinary delivery leadership
Directed the modeling effort as Project Lead, aligning scope, standards and quality across three disciplines.
- 02
Point-cloud-driven modeling
Oversaw the development of architectural, structural and MEP models directly from point cloud data.
- 03
Accuracy validation
Verified modeled existing elements against captured site conditions.
- 04
Early conflict identification
Ran cross-discipline clash detection ahead of design decisions.
Business outcome
consolidated into one validated existing-conditions baseline
applied before design: accuracy validation and clash detection
led end to end: team leadership, modeling, accuracy validation and clash detection
